Characteristics
- Combination of air breather filter and an air dryer
- Available in 4 sizes
- Refillable
- Replaceable air filter element (3µm glass fiber)
- Connection: stainless steel pipe with male BSP thread
- Available with optical indicator
Technical data
SF-part number
SBL 26050
SBL 26051
SBL 26052
SBL 26053
Volume(cm³)
300
600
1000
2000
Max. Water absorption (gr.)
86
172
288
576
Max. Flow rate (m³/min)
0.70
0.70
1.50
1.50
Dimensions (mm)
Ø 98 x 178
Ø 98 x 238
Ø 130 x 283
Ø 130 x 380
Thread (BSP)
G 3/4
G 3/4
G 1 1/4
G 1 1/4
Working temperature (°C)
-40 - +90
-40 - +90
-40 - +90
-40 - +90
Element
SBL 88033
SBL 88033
SBL 88038
SBL 88038
Humidity removal granulate
ZR-gel
ZR-gel
ZR-gel
ZR-gel
Indicator
red to orange
red to orange
red to orange
red to orange
Replacement granulate
SF-ZUB 70160
SF-ZUB 70151
SF-ZUB 70175
SF-ZUB 70147
Replacement AC granulate*
SF-ZUB 70596
SF-ZUB 70596
SF-ZUB 70596
SF-ZUB 70597
* 1/3 activated carbon granulate and 2/3 regular granulate .
Accessories
Description
Part number
Adapter for indicator (G 3/4)
SF-ZUB 70598
Adapter for indicator ( 1 1/4)
SF-ZUB 70600
Indicator
SF-ZUB 70599
All specifications refer to our standard product range. Due to constant technical developments, this information may change at any time without notice.You cannot find what you are looking for? Do not hesitate to contact us.
